Control Panel
Control Panel
T urning the Printer On and Off
T urning the printer on
1. Press the Power button to turn on the printer .
The printer will now start up.
After the Display Screen shows the Canon logo, Starting up... Please wait. is displayed.
2. The printer goes online in preparation for printing after startup, and the Online lamp and paper
source section lamp remain lit.
The printer will not go online in the following situations. T ake action as needed.
The T op Cover is open
Close the T op Cover .
The Ink T ank Cover is open
Close the Ink T ank Cover .
The Printhead is not installed
Install the Printhead. For the instruction, see “Replacing the Printhead”. (→P .627)
Ink T ank is not installed
Install the Ink T anks. For the instruction, see “Replacing Ink T anks”. (→P .616)
If “ERROR” is shown on the Display Screen
T urn of f the printer and contact your Canon dealer .
The Online lamp and Message lamp are not lit (even once), and nothing appears on the Display
Screen
Make sure the printer is plugged in correctly . Check the connection at the plug and electrical outlet.
Printer Parts 19

Table of Contents

Other manuals for Canon imagePROGRAF iPF610

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF610 and is the answer not in the manual?

Canon imagePROGRAF iPF610 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution2400 x 1200 DPI
Media thickness1.5 mm
Maximum print size610 x 1897 mm
Maximum roll length18 m
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A1, A2, A3
ISO B-series sizes (B0...B9)B2, B4
Maximum printable area203 mm
Compliance industry standardsIEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, suppliesPFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
DisplayLCD
Sound power level (standby)35 dB
Sound pressure level (printing)49 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet LAN data rates10base-T; 100base-TX Mbit/s
Ethernet interface typeFast Ethernet
Supported network protocolsIPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight77000 g
Bundled softwareimagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)6 W
Power consumption (typical)100 W
Power consumption (PowerSave)1 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Size (imperial)24 \
Dimensions (WxDxH)1177 x 670 x 348 mm
