Canon imagePROGRAF iPF610 User Manual

Windows
Main Sheet (W indows)
The following settings are available on the Main sheet. For details on settings items, refer to the printer
driver help.
Note
• On Main sheet, choose Easy Settings to specify basic print settings based on the print target, or switch
to Advanced Settings to complete more detailed settings as desired.
Conguration using Easy Settings
Setting Item Description
A Media T ype
Select the paper type.
For information on the types of paper the printer supports, refer to the Paper
Reference Guide . ( → P .1 12)
B Get Information Click to display the Get Information dialog box, which shows media types
and sizes by media source, as specied on the printer . When you select a
media source, your selection is applied to the printer driver settings for the
media source, media type, and roll width.
C Preferences
Click to display the Media Detailed Settings dialog box for ink drying time
and other detailed settings based on the paper type.
E Print T arget Choose presets that match the type of document to be printed.
Printing Photos and Images (Windows, Mac OS 9) (→P .207)
Printing Line Drawings and T ext (Windows, Mac OS 9) (→P .21 1)
Printing Of ce Documents (→P .213)
Depending on the Media T ype setting, some Print T arget options may
not be available.
F V iew Settings Click to display the V iew Settings dialog box, which enables you to conrm
the settings for the selected item from the E Print T arget list or change the
order of items listed in E Print T arget .
L Open Preview When Print
Job Starts
Activate this option to preview the print image before printing.
Conrming the Print Image Before Printing (→P .504)
Software 475

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
