Network Setting (Windows)
Specifying NetW are Print Services
Before printing in a NetW are network, you must congure print services such as print servers, print queues,
and so on. Y ou can congure the print service settings from a computer using any of the following software.
• NW ADMIN
• PCONSOLE
(from Novell, provided with NetW are)
Important
• If you use NW ADMIN to congure the print service settings, Novell Client (the Novell NetW are client
software) must be installed as the client software application.
• NetW are networking is unsupported in Windows V ista.
This topic gives instructions for conguring NetW are print services. The order of this procedure may vary
depending on the environment.
Choosing the type of print services
Before completing print service settings, choose the type of print service. Refer to the following descriptions
as needed.
Note
• In NetW are 5.1/6.0/6.5, NDPS may also be used as the print service. If you use NDPS, use the
Novell printer gateway included with NetW are. For details on conguring NDPS, refer to the NetW are
documentation.
• NDS (Novell Directory Service) and Bindery
NDS and bindery are both supported. Use the mode that is compatible with your network environment.
• Queue Server Mode and Remote Printer Mode
Queue server mode and remote printer mode are both supported.
• Queue Server Mode
When using queue server mode, all print server functions are supported, so there is no need for
other print server software or hardware. In NDS queue server mode (NDS PServer), the NDS
print server is used for printing. In bindery queue server mode (Bindery PServer), the bindery print
server is used for printing. Note that if you use queue server mode, a NetW are user license is
required for each network interface.
• Remote Printer Mode
In remote printer mode, the printer is controlled by the NetW are print server . Thus, a NetW are
print server is required. In NDS remote printer mode (NPrinter), the NDS print server is used for
printing, and in bindery remote printer mode (RPrinter), the bindery print server is used for printing.
576 Network Setting

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
