Canon imagePROGRAF iPF610 User Manual

Messages regarding printheads
Messages regarding printheads
Cannot adjust printhead.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .625)
2. Clean the Printhead if the nozzles are clogged.
( → P .626)
Highly transparent lm is loaded that cannot be used
for Printhead adjustment.
W e recommend using a type of paper that you often
use, other than lm, for Printhead adjustment.
( → P .599)
Cannot adjust band.
Cause Corrective Action
The Printhead nozzles are clogged. Follow the steps below to check the nozzles.
1. Print a test pattern to check the nozzles.
( → P .625)
2. Clean the Printhead if the nozzles are clogged.
( → P .626)
Highly transparent lm is loaded that cannot be used
for feed amount adjustment.
Adjust the feed amount manually .
( → P .607)
PHead needs cleaning.
Cause Corrective Action
The Printhead nozzles are clogged. Specify Printhead cleaning options. ( → P .626)
If the message is still displayed after Head Cleaning
B , contact the Canon dealer for assistance.
714 Error Message

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
