Control Panel
Paper Details
Setting Item Description, Instructions
Roll DryingT ime Specify the time to wait for the ink to dry for each sheet.
Scan W ait T ime Specify the time to wait for the ink to dry between each scan
in bidirectional printing, in consideration of how quickly the
ink dries. Note that printing will take longer if you specify a
wait time.
Feed Priority Specify exact paper feeding, if desired. Normally , select
Automatic . Choose Print Length if you prefer to feed
the paper an exact amount. However , note that choosing
Print Length may result in slight banding in the direction of
Carriage scanning.
Adjust Length Displayed if Feed Priority is Print Length .
Adjustment relative to the amount of stretching or shrinkage
of the current paper .
Enter either the adjustment results from Print Pattern or the
discrepancy that you measured (as a percentage).
For paper that tends to stretch, increase the feed amount by
choosing a higher adjustment value. For paper that tends
to shrink, decrease the feed amount by choosing a lower
adjustment value.
Head Height Adjust the Printhead height. ( P .603)
Skew Check Lv . If you print on Japanese paper (washi) or other handmade
paper that has an irregular width, choose Loose for a higher
skew detection threshold, or choose Off to disable skew
detection. However , if paper is loaded askew when detection
is Off , note that paper jams or Platen soiling may occur .
V acuumStrngth Specify the level of suction that holds paper against the
Platen . ( P .610)
NearEnd RollMrgn Specify the minimum margin at the leading edge of roll paper
to ensure better printing quality at the leading edge.
Note that if you choose 3mm , it may lower the printing quality
at the leading edge and af fect feeding accuracy . The printed
surface may be scratched, and ink may adhere to the leading
edge. It may also cause the Platen to become soiled.
Cut Speed Choose the cutting speed. If you use adhesive paper ,
choosing Slow helps prevent adhesive from sticking to the
cutter and keeps the cutter sharp.
T rim Edge First If a roll is loaded, the end of the paper will be cut.
(The paper type is
displayed here.)( *1 )
Cutting Mode Specify whether or not to cut with the standard round-bladed
cutter .
Choose Automatic to have the roll cut automatically after
printing. If you choose Manual , the paper will not be cut after
printing. Instead, a line will be printed at the cut position.
Choose Eject if you prefer not to have documents dropped
immediately after printing, as when waiting for ink to dry .
52 Printer Parts
