Handling rolls

Detection of the Remaining Roll Paper

If you have activated automatic detection of the remaining roll paper , when the roll is ejected, a barcode with text is

printed on the roll paper that identies the type of paper and amount left. If this function is activated and barcodes

are printed on the roll paper , the type of paper and amount left are automatically detected when you load a

roll. The barcode will be cut of f after it has been read.

Note

• If the document is not cut but kept in the printer , only the text message is printed. This is also the

case when printing on 8-inch rolls or clear lm.

Important

• If the barcode on the roll is not detected, enter the type and length of paper on the Control Panel .

Follow these steps to activate detection of the remaining roll paper .

1. Press the Menu button to display MAIN MENU .

2. Press ▲ or ▼ to select Media Menu , and then press the ► button.

3. Press ▲ or ▼ to select Chk Remain.Roll , and then press the ► button.

4. Press ▲ or ▼ to select the desired setting option, and then press the OK button.

Handling Paper 133

Other manuals for Canon imagePROGRAF iPF610

Questions and Answers:

Need help?

Do you have a question about the Canon imagePROGRAF iPF610 and is the answer not in the manual?

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR
