Canon imagePROGRAF iPF610 User Manual

Windows
Layout Sheet (W indows)
The following settings are available on the Layout sheet. For details on settings items, refer to the printer
driver help.
Setting Item Description
A Page Layout
Activate this setting to select a particular page layout.
Printing Multiple Pages Per Sheet (→P .385)
Printing Posters in Sections (→P .386)
Printing Multiple Originals Next to Each Other (→P .382)
Using PosterArtist to Compose Originals (→P .450)
C Set
Click to display one of the following dialog boxes depending on the selection
in A Page Layout . In these dialog boxes, you can specify layout details and
which pages to print, as well as other settings.
• Page Layout Printing
• Pages to Print
• Free Layout Settings
D W atermark Activating this option makes two settings available, E W atermarks and F
Edit W atermark .
Printing With W atermarks (→P .447)
E W atermarks Lists the provided watermarks. Choose the watermark to print.
F Edit W atermark Click to display the Edit W atermark dialog box for creating your own, original
watermark.
G Print Centered
Activate this setting to print document images in the center of the paper .
Printing Originals Centered on Rolls (→P .407)
Printing Originals Centered on Sheets (→P .408)
H Rotate 180 degrees Activate this option to rotate document images by 180 degrees before printing.
I No Spaces at T op or
Bottom (Conserve Paper)
Activate this setting to print the next image skipping blank areas above and
below printable data in documents, which enables you to conserve the paper .
Conserving Roll Paper by Printing Originals Without T op and Bottom Margins
(→P .425)
J Copies Enter the number of copies to print, in a range of “1-999.”
Reverse Order Activate this option to print pages in reverse order .
Collate Activate this option to print complete sets in the specied quantity .
Software 481

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
