Network Setting (Windows)
Specifying NetW are Protocols
Follow the steps below to congure NetW are protocol settings other than the frame type by using RemoteUI .
Note
For details on RemoteUI , see “Using RemoteUI”. (→P .570)
1. Start the web browser and enter the following URL in the Location (or Address ) box to display
the RemoteUI page.
http:// “printer IP address or name” /
Example: http://xxx.xxx.xxx.xxx/
2. Select Administrator Mode and click Logon .
3. If a password has been set on the printer , enter the password.
4. Click Network in the Device Manager menu at left to display the Network page.
5. Click Edit in the upper-right corner of the NetW are group to display the Edit NetW are Protocol
Settings page.
6. Make sure the Frame T ype indicates the frame type used on the NetW are network.
7. T o use burst mode, choose On for NCP Burst Mode .
Note
Burst mode supports fast data transfer when printing in queue server mode. Normally , choose On .
8. In Print Application , click the print service to be used.
Note
Only one print service selected here will be enabled. Multiple print services are not available at
the same time.
9. For packet signature, click If Requested by Server in Packet Signature .
10. Complete the following settings based on the selected service.
If you have selected Bindery PServer: Queue Server Mode (Using a Bindery Print Server)
1. In File Server Name , enter the le server name.
2. In Print Server Name , enter the name of the print server created in " Specifying NetW are
Print Services . (→P .576)"
3. In Print Server Password , enter the password of the print server created in " Specifying
NetW are Print Services . (→P .576)"
4. In Polling Interval , specify the interval at which the printer checks the NetW are print queue.
If you have selected RPrinter: Remote Printer Mode (Using a Bindery Print Server)
1. In Print Server Name , enter the advertising name of the print server created in " Specifying
NetW are Print Services . (→P .576)"
2. In Printer Number , enter the same printer number specied in " Specifying NetW are Print
Services . (→P .576)"
Network Setting 579
