Control Panel
System Setup
Setting Item Description, Instructions
Buzzer Set the buzzer . Choose On for the buzzer to sound once for
warnings and three times for errors.
W arning
Detect Mismatch Choose W arning for notication (display of a warning
message) during printing if the paper type specied in
the printer menu does not match the paper type in the
printer driver . Choose None to continue to print without
notication. Choose Pause to have printing paused under
these circumstances. In this case, you can continue printing
by pressing the Online button.
Keep Media Size Choose On to use the paper size setting as the basis for
printing instead of other settings. The margin setting of the
printer menu will be used instead of the margin setting of the
printer driver if the latter is smaller , which may prevent text or
images in the margin from being printed.
Choose Off to use the printer driver settings instead. Even if
the margin setting of the printer driver is smaller than that of
the printer driver , text or images will not be cut of f. However ,
this requires longer paper because the actual margin will
be equal to the margin setting of the printer driver plus the
margin setting of the printer menu.
Sht Selection If sheet size detection is activated, choose whether ISO A3+
or 13"x19"(Super B) is applied when an intermediate size is
detected.
Roll Selection 1 If roll size detection is activated, choose whether ISO A3
(297mm) or 300mm Roll is applied when a roll of an
intermediate width is detected.
Paper Size Basis
Roll Selection 2 If roll size detection is activated, choose whether 10in.
(254mm) or JIS B4 (257mm) is applied when a roll of an
intermediate width is detected.
T rimEdge Reload Choose On to cut the leading edge of the roll.
Noz. Check Freq. Specify the timing for automatic checks of nozzle clogging.
Choose 1 page to check once per printed page. Choose
10 pages to check once per ten printed pages. Choose
Automatic to have the printer automatically adjust the timing
for checks based on the frequency of nozzle use.
Sleep T imer Specify the period before the printer enters Sleep mode.
58 Printer Parts
