Other Maintenance
Other Maintenance
Preparing to T ransfer the Printer
T o protect the internal parts in transit, always follow the steps below before transferring the printer to a new
location. Refer to the Quick Start Guide for details on packing the printer and installing it after transfer .
Note
• It is not possible to prepare the printer for transfer if the Display Screen prompts you to replace the
Maintenance Cartridge or check the remaining capacity . Replace the Maintenance Cartridge before
transfer preparations. ( → P .634)
• Do not tilt the printer in transit. Ink inside the printer may leak and cause stains. If it is necessary to
stand the printer up or tilt it, contact your Canon dealer .
1. Remove the paper .
• Rolls ( → P .128) ( → P .123)
• Sheet ( → P .176) ( → P .196)
2. Press the Menu button to display MAIN MENU .
3. Press ▲ or ▼ to select Maintenance , and then press the ► button.
4. Press ▲ or ▼ to select Move Printer , and then press the ► button.
5. Press ▲ or ▼ to select Y es , and then press the OK button.
The printer now starts preparing for transfer .
If a message is shown on the Display Screen requesting you to open the Ink T ank Cover , follow
the procedure starting with step 6.
650 Maintenance

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
