Control Panel
Interface Setup
Setting Item Description, Instructions
EOP T imer Specify the timeout period before cancellation of print
jobs that cannot be received by the printer .
IP Mode Choose whether the printer IP address is congured
automatically or a static IP address is entered manually .
DHCP
BOOTP
Protocol
RARP
Specify the protocol used to congure the IP address
automatically .
IP Address
Subnet Mask
TCP/IP
IP Setting
Default G/W
Specify the printer network information when using a
static IP address.
Enter the IP address assigned to the printer , as well as
the network subnet mask and default gateway .
NetW are Specify the NetW are protocol. T o apply your changes,
choose Register Setting .
Frame T ype Specify the frame type to use.
NetW are
Print Service Choose the print service.
AppleT alk Specify whether to use the AppleT alk protocol. T o apply
your changes, choose Register Setting .
Auto Detect Specify the communication method. T o apply your
changes, choose Register Setting .
Choose On for automatic conguration of the LAN
communication protocol. Choose Off to use settings
values of Comm.Mode and Ethernet T ype .
Comm.Mode Choose the LAN communication method.
Ethernet T ype Choose the LAN transfer rate.
Spanning
T ree
Choose whether spanning-tree packets are supported
over the LAN.
Ethernet
Driver
MAC Address Displays the MAC address.
Ext. Interface Choose the expansion interface.
Return
Defaults
Return Defaults/Execute? is displayed if you press the
▼ button. Choose OK to restore the network settings
to the default values.
56 Printer Parts
