Canon imagePROGRAF iPF610 User Manual

Network Setting (Windows)
Specifying the frame type using the printer Control Panel
1. Press the Menu button to display MAIN MENU .
2. Press ▲ or ▼ to select Interface Setup , and then press the ► button.
3. Press ▲ or ▼ to select NetW are , and then press the ► button.
4. Press ▲ or ▼ to select NetW are , and then press the ► button.
5. Press ▲ or ▼ to select On , and then press the OK button.
Return to the NetW are menu.
6. Press ▲ or ▼ to select Frame T ype , and then press the ► button.
7. Press ▲ or ▼ to select the frame type to use, and then press the OK button.
Return to the NetW are menu.
8. Press ▲ or ▼ to select Print Service , and then press the ► button.
9. Press ▲ or ▼ to select the desired print service, and then press the OK button.
Return to the NetW are menu.
10. Press the Online button to bring the printer online.
If any of the settings is changed, a message for conrmation is displayed. In this case, press
the OK button.
Important
• Be sure to complete step 10. This will activate the values you have entered.
Note
• If an error message is displayed, check the settings and correct any invalid values.
• T o cancel the setup process, hold down the Stop button for a second or more.
Network Setting 575

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
