Page #64 background image
Control Panel
Main Menu Settings
Main menu items are described in the following tables.
For instructions on selecting or setting menu items, see “Main Menu Operations”. . (→P .30)
For details on menu levels and values, see “Menu Structure”. (→P .35)
Setting Item
Description, Instructions
Paper Cutting This command is available only if a roll is loaded.
Choose Y es to cut the roll at the current position. However , if paper cannot be
advanced to the cut position, it will not be cut. In this case, manually advance the
roll before cutting it. ( P .132)
Rep. Ink T ank When replacing the Ink T ank , choose Y es and follow the instructions on the screen.
( P .616)
Head Cleaning Specify Printhead cleaning options. ( P .626)
Choose Head Cleaning A if printing is faint, oddly colored, or contains foreign
substances.
Choose Head Cleaning B if no ink is printed at all, or if printing is not improved
by Head Cleaning A .
Media Menu Specify the type and size of paper . ( P .51)
Paper Details Specify detailed paper-related settings, including the ink drying time and borderless
printing options. ( P .52)
GL2 Settings Specify settings for HP-GL/2 printing. ( P .54)
Adjust Printer Adjust the Printhead alignment or amount of feed by printing a test pattern. ( P .55)
Interface Setup Congure the EOP timer and network settings. ( P .56)
Maintenance Access maintenance settings when replacing the Printhead or preparing to move
the printer . ( P .57)
System Setup Specify the printer system settings, including the date format and display language.
( P .58)
T est Print Choose Status Print to print information about the printer .
Choose Media Details to print the paper settings as specied in Paper Details .
Choose Print Job Log to print a record of print jobs, including the paper type and
size, amount of ink used, and so on. (Information on ink consumption is general,
not specic in nature.)
Choose Menu Map to print a list of the main menu options.
Choose Nozzle Check to print a test pattern for checking the nozzles.
Information Displays information about the printer and record of print jobs. ( P .60)
