Canon imagePROGRAF iPF610 User Manual

Printing does not start
Printing does not start
The Data lamp on the Control Panel does not light up
Cause Corrective Action
The printer is not on. Make sure the power cord is securely plugged in, all the way . Press the
Power button to turn the printer on.
In Windows, select the printer by clicking Select Printer or Printer in
the printing dialog box and try printing again.
In Mac OS X, select the printer by clicking Printer Setup Utility (or
Print Center ) and try printing again.
The printer is not selected in the
printer driver . (The printer is in
Sleep mode.)
In Mac OS 9, select the printer in Chooser and try printing again.
In Windows, restart the print job as follows.
1. Select the printer icon in the Printers and Faxes (or Printers )
window .
2. Clear Pause Printing in the File menu to restart the print job.
In Mac OS X, restart the print job as follows.
1. Open the Printer Setup Utility (or the Print Center ).
2. Select the printer , and then Start Jobs in the Printers menu to
restart the print job.
The print job is paused. (The
printer is in Sleep mode.)
In Mac OS 9, restart the print job as follows.
1. Open imagePROGRAF Printmonitor .
2. Choose Resume Printing in the File menu to restart the print job.
The Printer Does Not Respond Even if Print Jobs are Sent
Cause Corrective Action
The printer is of ine. Press the Online button on the Control Panel to bring the printer online.
The Display Screen indicates the system is lling with ink
Cause Corrective Action
When the printer was turned of f previously , some
cleaning operation was terminated.
W ait until the system has been lled with ink. This
process may take about ten minutes.
T roubleshooting 659

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
