Network Setting

Initializing the Network Settings

Use RemoteUI to restore the network settings to the default values as follows.

Important

• Initializing the network settings will also restore the default value of the printer ’ s IP address. As a result,

the RemoteUI page cannot be displayed in the web browser after this procedure.

• For instructions on reconguring the IP address, see “Conguring the IP Address on the Printer”.

(→P .562)

• For details on RemoteUI , see “Using RemoteUI”. (→P .570)

1. Start the web browser and enter the following URL in the Location (or Address ) box to display

the RemoteUI page.

http:// “printer IP address or name” /

Example: http://xxx.xxx.xxx.xxx/

2. Select Administrator Mode and click Logon .

3. If a password has been set on the printer , enter the password.

4. Click Network in the Device Manager menu at left to display the Network page.

5. Click Reset to Default settings in the lower-right corner of the Network Interface group.

6. After conrming the message, click OK to restore the network settings to the default values.

Note

• Y ou can also use imagePROGRAF Device Setup Utility or the Control Panel to restore the default

network settings.

• If you use the Control Panel to initialize the network settings, press the Menu button to display MAIN

MENU , and then press ▲ , ▼ , and ► to select Interface Setup → Ethernet Driver → Init. Settings →

Y es (in this order), and nally press the OK button.

Network Setting 563

Other manuals for Canon imagePROGRAF iPF610

Questions and Answers:

Need help?

Do you have a question about the Canon imagePROGRAF iPF610 and is the answer not in the manual?

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR
