Canon imagePROGRAF iPF610 User Manual

Installation problems
Removing Installed Printer Drivers
Follow the steps below to remove installed printer drivers and utilities.
Removing printer drivers (W indows)
Remove the printer driver as follows.
Note
• In Windows 2000/Windows XP/Windows Server 2003/Windows V ista, you must log on with
administrative rights such as “Administrator” account.
1. From the Windows start menu, select Programs > Canon Printer Uninstaller >
imagePROGRAF Printer Driver Uninstaller to display the Delete Printer window .
2. Select the printer in the list and click Delete .
3. Click Y es in the W arning message dialog box.
4. Make sure that the printer has been removed from the list, and click Exit .
Removing Printer Drivers and imagePROGRAF Printmonitor
(Macintosh)
Remove the printer driver or imagePROGRAF Printmonitor as follows.
1. Insert the User Software CD-ROM provided with the printer in the CD-ROM drive.
2. Start the printer driver installer included in the User Software CD-ROM .
For Mac OS X, open OS X and double-click iPF Driver Installer X .
For Mac OS 9, open OS 9 and double-click iPF Driver Installer 9 .
3. In the upper-left menu, choose Uninstall , and click Uninstall .
4. Follow the instructions on the screen to remove the printer driver or imagePROGRAF
Printmonitor .
Removing imagePROGRAF Status Monitor (W indows)
Remove imagePROGRAF Status Monitor as follows.
1. From the Windows start menu, select Programs > imagePROGRAF Status Monitor >
Uninstaller (imagePROGRAF Status Monitor) to start the wizard.
2. In the wizard window , click Delete , and then click Next .
3. Follow the instructions on the screen to remove imagePROGRAF Status Monitor .
Removing imagePROGRAF Device Setup Utility (W indows)
Remove imagePROGRAF Device Setup Utility as follows.
1. From the Windows start menu, select Programs > imagePROGRAF Device Setup Utility >
Uninstaller (imagePROGRAF Device Setup Utility) to start the wizard.
2. In the wizard window , click Delete , and then click Next .
3. Follow the instructions on the screen to remove imagePROGRAF Device Setup Utility .
674 T roubleshooting

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
