Problems with the printing quality
The surface of the paper is dirty
Cause Corrective Action
The Paper Retainer is soiled. Clean the Paper Retainer . ( P .647)
Y ou are using a paper that does not dry easily . Specify a time of about a minute in Roll DryingT ime .
The back side of the paper is dirty
Cause Corrective Action
The Platen has become dirty after borderless printing
or printing on small paper .
Open the T op Cover and clean the Platen .
( P .644)
The Paper Retainer is soiled. Clean the Paper Retainer . ( P .647)
Banding in different colors occurs
Cause Corrective Action
The roll is not loaded correctly in the Roll Feed Unit . Remove the roll and reload it.
( P .124)
The paper feed amount is not adjusted correctly . Adjust the feed amount.
( P .604)
Printing does not proceed smoothly because print
jobs are interrupted during transmission.
Exit other applications and cancel other print jobs.
In the printer menu, Print Length is specied in
Feed Priority .
T o adjust the feed amount, specify Band Joint in
Feed Priority in the printer menu.
( P .604)
The Printhead is out of alignment. Adjust the Printhead alignment.
( P .599)
Streaks may occur if you set the Print Quality too
low .
Choose a higher level of Print Quality in the
Advanced Settings of the printer driver and try
printing again.
( P .203)
The contrast becomes uneven during printing
Cause Corrective Action
Adjust the feed amount.
( P .604)
The paper feed amount is out of adjustment.
Execute Fine Band Adj. during printing.
( P .604)
668 T roubleshooting
