Canon imagePROGRAF iPF610 User Manual

Handling rolls
6. Specify the type and length of the paper .
How the printer operates after the paper is fed varies depending on the setting for automatic
detection of the remaining roll paper , as well as the barcode printed on rolls.
Automatic Detection of the
Remaining Roll Paper
Barcodes
Printer Operation After the Paper is Fed
Printed The type and amount of paper left is automatically
detected based on the barcode printed on the roll.
There is no need to specify the type and length of
the paper .
On
Not printed Y ou must specify the type and length of the paper .
A menu for selection of the paper type and length
is automatically shown on the Display Screen .
( → P .130)
( → P .131)
PrintedOf f
Not printed
Y ou must specify the type of paper .
( → P .130)
7. Close the Roll Feed Unit Cover with one hand, as shown.
8. If the edge of the roll is bent or soiled, cut the edge of the paper .
1. Press the Online button to bring the printer of ine.
2. Press ▲ or ▼ to feed the roll paper to the position for cutting.
3. Select Y es in Paper Cutting on Printer Menu, and then press the OK button. ( → P .135 )
Handling Paper 127

Canon imagePROGRAF iPF610 Specifications

General

Color	Yes
Printing colors	Black, Blue, Cyan, Green, Magenta, Pigment cyan, Pigment magenta, Red, Yellow
Maximum resolution	2400 x 1200 DPI
Media thickness	1.5 mm
Maximum print size	610 x 1897 mm
Maximum roll length	18 m
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A1, A2, A3
ISO B-series sizes (B0...B9)	B2, B4
Maximum printable area	203 mm
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Compatible ink types, supplies	PFI-101 (130ml, C, M, Y, PC, PM, R, G, B), PFI-103 (130ml, BK, MBK, GY, PGY)
Display	LCD
Sound power level (standby)	35 dB
Sound pressure level (printing)	49 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10base-T; 100base-TX Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	IPX/SPX (Netware 3.2(J), 4.1 (J), 4.11(J), 4.2(J), 5.0(J), 5.1(J) SNMP (Canon-MIB), HTTP, TCP/IP, AppleTalk
Package weight	77000 g
Bundled software	imagePROGRAF Printer Driver 2007 (Win/Mac), imagePROGRAF Status Monitor Media Configuration Tool Print Plug-in f/ Photoshop Print Plug-in f/ Digital Photo Pro Digital Photo Front-Access
Power consumption (standby)	6 W
Power consumption (typical)	100 W
Power consumption (PowerSave)	1 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows 2000, XP, Vista 32 bit/64 bit Macintosh OS 9, OS 10, Leopard
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Size (imperial)	24 \
Dimensions (WxDxH)	1177 x 670 x 348 mm
