Adjusting the Printhead
2. Press the Menu button to display MAIN MENU .
3. Press or to select Adjust Printer , and then press the button.
4. Press or to select Auto Head Adj. , and then press the button.
5. Press or to select Advanced Adj. , and then press the button.
6. Press or to select Y es , and then press the OK button.
A test pattern is printed for printhead adjustment.
After reading the pattern, the printer automatically adjusts the Printhead alignment.
Note
If paper is fed automatically and no roll is loaded, select the media source and click the OK button.
Additionally , when Cassette is selected as the paper source, choose the type and size of paper .
600 Maintenance
