9-SPECIFICATIONS
631093593
MEDIUMRADIALFRAMEWHEELUNITS(SR175)
ITEM
COMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)3895mm(153.4in)
B
Heighttobuckethingepin(FullyRaised)3099mm(122in)
CT opofRollOverProtectiveStructure(ROPS)1974mm(77.7in)
DHighestLevelBucketHeight
2925mm(115.2in)
E
OverallLength(NoAttachment)2685mm(105.7in)
F
OverallLength(WithstandardBucket)3305mm(130.1in)
GDumpAngle(FullyRaised)39.6°
H
DumpHeight(MaximumReach)atfulldumpangle2470mm(97.2in)
J
DumpReach(FullyRaised)atfulldumpangle542mm(21.3in)
K
MaximumRollbackatGround31.6°
L
MaximumRollback(FullyRaised)98.6°
MWheelBase
1128mm(44.4in)
P
GroundClearance(BellyPan)178mm(7in)
QAngleofDeparture23°
URearAxletoBumper
924mm(36.4in)
NOTE:Measurementsarebasedonmachineswith10x16.5tiresanda1676.4mm(66.0in)Dirt&Foundry(DF)
bucket.
9-5
