9-SPECIFICATIONS
631093615
MEDIUMVERTICALFRAMEWHEELUNIT(SV185)
ITEM
COMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)3820mm(150.4in)
B
HeighttoHingePin(FullyRaised)3048mm(120in)
CCabHeight1974mm(77.7in)
DHighestLevelBucketHeight
2877mm(113.3in)
E
OverallLength(NoAttachment)2685mm(105.7in)
F
OverallLength(WithstandardBucket)3345mm(131.7in)
GDumpAngle(FullyRaised)51.9°
H
DumpHeight(MaximumReach)2380.0mm(93.7in)
J
DumpReach(FullyRaised)783mm(30.8in)
K
MaximumRollback@Ground35°
L
MaximumRollback(FullyRaised)87.6°
MWheelBase
1128mm(44.4in)
P
GroundClearance(BellyPan)178mm(7in)
QAngleofDeparture23°
URearAxletoBumper
924mm(36.4in)
NOTE:Measurementsarebasedonmachineswith10x16.5tiresanda1676.4mm(66.0in)Dirt&Foundry(DF)
bucket.
9-7
