CASE CONSTRUCTION Alpha Series - Page 264

9-SPECIFICATIONS
RAIL14SSL0433FA6
MEDIUMVERTICALFRAMEWHEELUNIT(SV185)
ITEM
COMPONENTMEASUREMENT
R
Clearancecircleradiuswithouttool1347.0mm(53.0in)
SClearancecircleradiuswith1676.4mm(66.0in)DF
bucket
2037.0mm(80.2in)
SClearancecircleradiuswith1676.4mm(66.0in)LP
bucket
2133.0mm(84.0in)
SClearancecircleradiuswith1676.4mm(66.0in)LPE
bucket
2251.0mm(88.6in)
T
Clearancecircleradiusrear1599.0mm(63.0in)
V
Overthetirewidth1371.0mm(54.0in)
W
Overallwidth1642.0mm(64.6in)
Operatingweight2980kg(6570lb)
SAERatedOperatingCapacity(ROC)840kg(1852lb)
Tippingload
1678kg(3699lb)
Counterweight(optional)63.8kg(140.7lb)
Cabsideglass(optional)21.3kg(47.0lb)
Cabglassdoor(optional)34.0kg(75.0lb)
CabLexandoor(optional)34.0kg(75.0lb)
Suspensionseat(optional)10.0kg(22.0lb)
NOTE:Measurementsarebasedonmachineswith10x16.5tiresanda1676.4mm(66.0in)Dirt&Foundry(DF)
bucket.
NOTE:ClearanceCircleRadius(R,S,T)valueswerecalculatedusinga50/50weightdistribution(centerpointof
counterrotationcenteredbetweentheaxles)andwiththebucketrestingatonground.
9-8
