9-SPECIFICATIONS
631093597
MEDIUMRADIALFRAMEWHEELUNITS(SR200)
ITEM
COMPONENTMEASUREMENT
A
OverallOperatingHeight(FullyRaised)3920mm(154.3in)
B
HeighttoHingePin(FullyRaised)3124mm(123in)
CCabHeight1998mm(78.7in)
DHighestLevelBucketHeight
2950mm(116.1in)
E
OverallLength(NoAttachment)2669mm(105.1in)
F
OverallLength(WithstandardBucket)3292mm(129.6in)
GDumpAngle(FullyRaised)39.6°
H
DumpHeight(MaximumReach)2495mm(98.2in)
J
DumpReach(FullyRaised)517mm(20.3in)
K
MaximumRollback@Ground31.0°
L
MaximumRollback(FullyRaised)98.6°
MWheelBase
1128mm(44.4in)
P
GroundClearance(BellyPan)203mm(8in)
QAngleofDeparture25°
URearAxletoBumper
924mm(36.4in)
NOTE:Measurementsarebasedonmachineswith12x16.5tiresanda1829mm(72in)Dirt&Foundry(DF)
bucket.
9-9
