Casio QT-6000 Service Manual

— 101 —
29. XC6206P182MR (IC34)
PIN ASSIGNMENT
BLOCK DIAGRAM
NAME
Ground
VOUT
Power InputVIN
PIN NUMBER
PIN
FUNCTION
2
3
VSS1
Output
1
2
3
VIN
VOUTVSS
Current
Limi
t
Voltage
Referenc
e
V IN V OUT
V SS
30. XC6219B332MR (IC46)
PIN ASSIGNMENT
BLOCK DIAGRAM
NAME
Input
VSS
PIN NUMBER
PIN
FUNCTION
2
VIN1
Ground
ON/OFF Control
NC
Output VOUT
4
5
CE3
No Connection
Current
Limit
ON/OFF
Control
Voltage
Reference
each circuit
CE
V
SS
VOUT
VIN
R2
R1
4
231
5
CE
(NC)
V
IN
V SS
V OUT

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
