Casio QT-6000 Service Manual

— 13 —
■ QT-6060D
1. Remove four screws.
2. Release the connector and remove the IO PCB.
3. Remove four screws and separate the unit as shown below.
Screw × 4
Connector
Screw × 4
4. Remove the cap.
5. Remove four screws under both packing.
Screw × 2
Screw × 2

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
