— 1 —
1. SPECIFICATIONS
1-1. Electrical Specifications
1-2. Environmental specifications
1-3. Main LSI specifications
CPU Name HD6417751RF240 (SH-4)
Number of control bit 32 bits
I/O controller Name UPD78F4216AGC8EUDA01
Number of control bit 16 bits
Gate array Name UPD65945GJ-P16-JEU
SDRAM Name EDS2532AABH-75L
Capacity 256 Mbits
Flash ROM Name MBM29QM12DH
Capacity 128 Mbits
Display controller Name SM712GX020000-AA
ADPCM speech LSI Name MSM9841GS-2K
Ethernet controller Name LAN91C113-NE (10/100BASE TX)
PCMCIA controller Name R5C485-LQFP144
Operating temperature 0 °C ~ 40 °C
Operating humidity 20 % ~ 85 %
Storage temperature -20 °C ~ 65 °C
Storage humidity 10 % ~ 85 %
120V 220V 230V 240V
• Power consumption <AC input current at Adaptor>
In operation 1.1A 1.1A 1.1A 1.1A
Display off 0.25A 0.15A 0.14A 0.13A
<DC input current at QT-6000>
In operation 0.9A 0.9A 0.9A 0.9A
Display off 0.5A 0.5A 0.5A 0.5A
• Memory protection Back-up battery NiMH (nickel-metal-hydride)
HHR-21HL3G1B (USA only)
HHR-21HL3G1C (Except USA)
Back-up period 30 days (25 °C)
Battery life Replace the battery every 5 years.
Recharge time 24 hours (full charge)
• Clock & Calendar Accuracy Within ± 40 sec. Per month (25 °C)
Auto calendar Effective until 2099 A.D.
