Casio QT-6000 Service Manual

— 127 —
1. MAIN PCB BLOCK
N 1 1016 5847 PCB ASSY/E820-1 RJE501150*001 1 1 1 A
N IC26 1016 4750 LSI HD6417751RF240 1 1 1 CT B
N IC44 1016 4748 LSI D78F4216AGC8EUDA01 1 1 1 CL B
IC14 1007 3986 LSI UPD65945GJ-P16-JEU 1 1 1 BU B
N IC1 1017 8771 LSI 29QM12DH60PCNKE102 1 1 1 B
N IC12 LSI EDS2532AABH-75L-E 1 1 1 X
N IC40 1016 4752 LSI IDT2305-1DC 1 1 1 AU B
N IC28 1016 4751 LSI LAN91C113-NE 1 1 1 CB B
N IC15 1016 4753 LSI MSM9841GS-2K 1 1 1 BJ B
N IC36 1016 4755 LSI R5C485-LQFP144 1 1 1 BY B
N IC45 LSI SM712GX020000-AA 1 1 1 X
IC33 2112 0763 IC/RESET M51957BFP-T1 1 1 1 AJ C
N IC3,9,23,27 1016 6792 IC HIN211CAZ-T 4 4 4 C
N IC24 1016 6793 IC HIN202CBNZ-T 1 1 1 C
N IC35 1016 6794 EEPROM BR93L46RF-WE2 1 1 1 C
N IC41 1016 6797 IC SG-8002JFSCB14.318M 1 1 1 C
N IC43 1016 6796 IC SG-8002JFSCB33M 1 1 1 C
IC2 1007 4003 IC XC6365A363MR 1 1 1 AG C
N IC42 1016 6798 IC XC62EP1502MR 1 1 1 C
N IC46 1016 5673 IC XC6219B332MR 1 1 1 AB C
N IC34 1016 6799 IC XC6206P182MR 1 1 1 C
N IC18 1008 1012 IC LM4876MM 1 1 1 C
IC6,7 1010 5408 IC/CMOS SN74LVC245APWR 2 2 2 AA C
IC4,5 1010 5407 IC/CMOS SN74LVC244APWR 2 2 2 AA C
N IC11 1016 6801 IC/CMOS SN74LVC138APWR 1 1 1 C
IC25 1000 4414 IC/CMOS SN74LV74APWR 1 1 1 AC C
IC16,21,50,51 1000 5662 IC/CMOS SN74LV374APWR 4 4 4 AF C
IC48,52-54 1000 4413 IC/CMOS SN74LV32APWR 4 4 4 AB C
IC22,38,39 1000 5721 IC/CMOS SN74LV244APWR 3 3 3 AF C
IC30 1000 7179 IC/CMOS SN74LV10APWR 1 1 1 AC C
IC47,57 1000 5659 IC/CMOS SN74LV08APWR 2 2 2 AB C
IC37 1010 5417 IC/CMOS SN74LV07APWR 1 1 1 AA C
IC10 1012 0129 IC/CMOS SN74LV04APWR 1 1 1 AC C
IC29 1000 3984 IC/CMOS SN74LV00APWR 1 1 1 AB C
N IC32 1016 6802 IC/CMOS SN74HC148NSR 1 1 1 C
N IC8 1016 6803 IC/CMOS SN74ALVCH16245DGGR 1 1 1 C
N IC13,17 1016 6804 IC/CMOS SN74ALVCH16244DGGR 2 2 2 C
N IC20 1016 6805 IC/CMOS SN74ALVC08PWR 1 1 1 C
IC49 1010 5416 IC/CMOS SN74AHCT08PWR 1 1 1 AC C
R55,65,70,77-83,85-87,
RESISTOR/CHIP
CR1/16-000V 29 29 29 X
R92,93,97,99,100,105,
R109,110,115,121,127,
R176,179,243,294,295
R118,129,130,133,
RESISTOR/CHIP
CR1/16-101JV 8 8 8 X
R340-343
R1,11,40,120,128,240,
RESISTOR/CHIP
CR1/16-102JV 10 10 10 X
R250,275,314
R7,12-18,23-30,32,34,
RESISTOR/CHIP
CR1/16-103JV 147 147 147 X
R35,37,41-48,54,62,64,
R96,103,108,113,135-
174,183-192,199,
R200,202-212,224-234,
R237-239,241,244,245,
R251,253,254,257-260,
R263,269-271,296,
R298-308,311-313,
R315-318,331,335
N Item Code No. Parts Name
Price
Code
Rank
Q'ty
Specification
Standard
Model
Other
Dallas
key
Model
Standard
Model
USA

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
