Casio QT-6000 Service Manual

— 130 —
N Item Code No. Parts Name
Price
Code
Rank
Q'ty
Specification
Standard
Model
Other
Dallas
key
Model
Standard
Model
USA
CN8 1007 3685 CONNECTOR TM3RA-88 1 1 1 AZ C
N CN9 1016 6383 CONNECTOR DS9094F 1 1 1 AX C
N SW2 1018 1764 CONNECTOR 9202B-1-02Z040-PT1 1 1 1 C
CN1 1007 4494 GUIDE/CF CARD FCN-560HAC 1 1 1 AP C
N VR3 1016 6790 VOLUME RH0411CS4J 1 1 1 C
SW1 1012 0119 SWITCH/PUSH SKHHLSA010 1 1 1 AC C
31 1016 5835 CABLE SUB ASSY/S1 RJE501162*001V01 1 1 1 C
NUT/6 N-HXT2-2ZC 2 2 2 X
SCREW/BIND S-BDMA-2X5ZC 6 6 6 X
N CN7 1018 1765 EJECTOR/PC CARD ICME-CB68L5-302NLF 1 1 1 C
N IC19 1016 6795 IC RTC-7301DG 1 1 1 C
N VR4 1018 1766 VOLUME/ROTARY EVUE20H20B14 1 1 1 C
RESISTOR RD25SM10-6102J 1 1 1 X
CAPACITOR ECQ-V1H104JZW 2 2 2 X
DIODE RB441Q-40T-77 1 1 1 X
2. LCD BLOCK
N 2
1016 5844 CHASSIS/LCD E820 RJE501107-001V01
111
C
N 3
1016 5845 HOLDER/LCD E820 RJE501138-001V01
444
C
N 4
1016 5846 CUSHION/LCD E820 RJE501132-001V01
111
X
N 5
1018 3836 INVERTER PS10206
111
A
N 6
1016 5848 INSULATOR/INV E820 RJE501129-001V01
111
X
SPACER/ROCKING RSPLS-8
333
X
SPACER/ROCKING RSPLS-18L
222
X
SCREW/PAN SEMS S-PASEMA-3X6ZC
444 X
SCREW/PAN SEMS S-PASLMA-3X6ZC
888 X
N 7
1016 4747 LCD NL8060BC31-27
111
EQ A
N 8
1016 4757 PANEL/TOUCH N010-0550-T711
111
DL A
N 9
1017 9186 FPC ASSY/E820 RJE501236*001V01
111
C
N
1017 0323 TAPE/LCD E820 RJE501211-001V01
111
C
3. FRONT CASE BLOCK
N
10
1018 3838 CASE SUB ASSY/FRONT RJE501231*001V01
1
C
N 10
1018 3840 CASE SUB ASSY/FRONT RJE501231*002V01 1
1
C
10 1032 4536 CASE/FRONT RJE501081-001V03 1 1 1 C
10-1 1018 2639 PLATE/CASIO E820 RJE501249-001V01 1 1 1 C
10-2 1030 1133 COVER/DALLAS RJE501089-001V02 1 1 C
10-3 1016 5819 CHASSIS/NUT RJE501118-001V01 1 1 1 X
N
11 1016 5817 SEAL/LCD E820 RJE501104-001V01 1 1 1 C
N
12 1016 5818 PLATE/MIC EARTH E820 RJE501119-001V01 1 1 1 C
N
13 1016 5820 PCB ASSY/E820-MIC RJE501158*001V01
1
11
A
N 14
1016 5821 BUTTON/DP E820 RJE501091-001V01 1
11
C
N 15
1016 5822 COVER/DP LAMP E820 RJE501092-001V01 1
11
C
N 16
1016 5823 COVER/DP SW E820 RJE501090-001V01 1
11
C
N 17
1016 5824 SEAL/MCR E820 RJE501106-001V01 1
11
C
N 18
1016 5825 CHASSIS/LR E820 RJE501108-001V01 1
11
C
N 19
1016 5826 CHASSIS/B E-820 RJE501109-001V01 1
11
C
N 20
1016 5827 CHASSIS/CON E820 RJE501111-001V01 1
11
C
N 21
1016 5828 CHASSIS/SW E820 RJE501114-001V01 1
11
C
N 22 1016 5829
CHASSIS/T E820
RJE501115-001V01 1 1 1 C
SCREW/WASHER PT S-WBPT-3X6ZC 6 6 5 X
N 23 1016 5833 IBUTTON ASSY RJE501183*001V01 1 C
N 24 1016 6867
SWITCH/POWER
SDDJE10700 1 1 1 C
N 25 1016 5835
CABLE SUB ASSY/S1
RJE501162*001V01 1 1 1 C
N 26 1016 5836
CABLE SUB ASSY/CNB
RJE501165*001V01 1 1 1 C
N 27 1016 5837
CABLE SUB ASSY/MIC
RJE501166*001V01 1 1 1 C
N 28 1017 2645
BATTERY/NIH
HHR-21HL3G1C 1 1 CS A
N 28 1017 2644
BATTERY/NIH
HHR-21HL3G1B 1 CS A
TIE/CABLE
BK-1 2 2 2 X
N 29 1016 5839
CABLE SUB ASSY/CNB
RJE501165*002V01 1 1 1 C
N 30 1016 5840
CABLE SUB ASSY/CNB
RJE501165*003V01 1 1 1 C

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
