Casio QT-6000 Service Manual

— 50 —
[ 28 ] Sound recording test
[Function]
This test will check the sound recorded by the internal or external microphone.
The test records sound for three seconds, followed by the playback of the recorded data at the
maximum volume.
[Operation]
Operation : 9 8 ST
Press [OK] or [NG] key to end the test.
"OK" = 1
"NG" = 9
[LCD]
[ 29 ] Charging test
[Function]
This test will turn off the charging function.
[Operation]
Operation : 9 9 ST
[LCD]
CAHRGE OFF 99
END 99
CAHRGE OFF 99
END 99
MIKE 98
MIKE OK
END 98
MIKE 98
MIKE OK
END 98
[Print]
[Print]

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
