— 66 —
8-9. G/A (IC14: uPD65945GJ-093-JEU)
8-9-1. Pin Function
PIN NO PIN NAME I /O DESCRIPTIN PIN NO PIN NAME I / O DESCRIPTIN
1 VDD VDD VDD 73 VDD VDD VDD
2 GD0 I/O ARC DATA (D0) 74 CLKOUT O CLOCK 8MHz
3 GD1 I/O ARC DATA (D1) 75 CLKIN I CLOCK 8MHz
4 GD2 I/O ARC DATA (D2) 76 GND I GND
5 GD3 I/O ARC DATA (D3) 77 CS I Chip Select 5
6 GD4 I/O ARC DATA (D4) 78 A0 I ADDRESS (A1)
7 TVDD VDD VDD 79 A1 I ADDRESS (A2)
8 TGND GND GND 80 A2 I ADDRESS (A3)
9 GD5 I/O ARC DATA (D5) 81 A3 I GND
10 GD6 I/O ARC DATA (D6) 82 A23 I ADDRESS (A23)
11 GD7 I/O ARC DATA (D7) 83 A20 I ADDRESS (A20)
12 GD8 I/O VDD 84 A21 I ADDRESS (A21)
13 GD9 I/O VDD 85 A22 I ADDRESS (A22)
14 TGND GND GND 86 RD I IO READ
15 GD10 I/O VDD 87 WE I IO WRITE
16 GD11 I/O VDD 88 INT6 I INT for ARC
17 GD12 I/O VDD 89 INT7 I Int for PCMCIA
18 GD13 I/O VDD 90 TVDD VDD VDD
19 GD14 I/O VDD 91 RESET I RESET
20 TVDD VDD VDD 92 RD_WE I READ/WRITE signal
21 TGND GND GND 93 TESTB I VDD
22 GD15 I/O VDD 94 U1_CTSB I CST2
23 GA0 O ARC ADDRESS (A0) 95 U1_DSRB I DSR2
24 GA1 O ARC ADDRESS (A1) 96 U1_SIN I RXD2
25 GA2 O ARC ADDRESS (A2) 97 U1_DTRB O DTR2
26 GA3 O Not used 98 U1_RTSB O RTS2
27 TGND GND GND 99 U1_SOUT O TXD2
28 D0 I/O DATA (D0) 100 U2_CTSB I CTS3
29 D1 I/O DATA (D1) 101 U2_DSRB I DSR3
30 D2 I/O DATA (D2) 102 U2_SIN I RXD3
31 TVDD VDD VDD 103 U2_DTRB O DTR3
32 TGND GND GND 104 U2_RTSB O RTS3
33 D3 I/O DATA (D3) 105 U2_SOUT O TXD3
34 D4 I/O DATA (D4) 106 U3_CTSB I CTS4
35 D5 I/O DATA (D5) 107 U3_DSRB I DSR4
36 VDD VDD VDD 108 VDD VDD VDD
37 GND GND GND 109 GND GND GND
38 GND GND GND 110 GND GND GND
39 D6 I/O DATA (D6) 111 U3_SIN I RXD4
40 D7 I/O DATA (D7) 112 U3_DTRB O DTR4
41 D8 I/O VDD 113 U3_RTSB O RTS4
42 TGND GND GND 114 U3_SOUT O TXD4
43 D9 I/O VDD 115 U4_CTSB I VDD
44 D10 I/O VDD 116 U4_DSRB I VDD
45 D11 I/O VDD 117 U4_SIN I VDD
46 TVDD VDD VDD 118 U4_DTRB O NOT USED
47 TGND GND GND 119 U4_RTSB O NOT USED
48 D12 I/O VDD 120 U4_SOUT O NOT USED
49 D13 I/O VDD 121 U5_CTSB I VDD
50 D14 I/O VDD 122 U5_DSRB I VDD
51 TGND GND GND 123 U5_SIN I VDD
52 D15 I/O VDD 124 U5_DTRB O NOT USED
53 INTC2 O INT for ARC 125 U5_RTSB O NOT USED
54 INTC1 O INT for UART 126 U5_SOUT O NOT USED
55 GCS1 O Chip Select for ARC 127 TVDD VDD VDD
56 GCS2 O EST-CS 128 PCMIN I PCMCD1
57 GRD O Read signal for ARC 129 CE1B I CE1
58 GWE O Write signal for ARC 130 CE2B I CE2
59 PCIN O PCMCIA IN/OUT signal 131 CFIN I CFCD1
60 PCMG O Enable for PCMCIA 132 CE1A I CE1
61 CFCE1A O Chip Enable1 for CF CARD 133 CFCE I ADDRESS (A23)
62 CIN O CF CARD IN/OUT signal 134 CE2A I CE2
63 CFG O Enable for CF CARD 135 BFI1 I CI1
64 CFCE2A O Chip Enable2 for CF CARD 136 BFI2 I CD1
65 ANDO1 O WAIT signal 137 BFI3 I RXD1
66 ANDO2 O DSR 138 BFI4 I CTS1
67 BFO1 O CI 139 ANDI1 I WAIT for CF CARD
68 BFO2 O CD 140 ANDI2 I WAIT for PCMCIA
69 BFO3 O RXD 141 ANDI3 I DSR1
70 BFO4 O CTS 142 ANDI4 I DSR1
71 GND GND GND 143 GND GND GND
72 GND GND GND 144 GND GND GND
To Next Page
