Casio QT-6000 Service Manual

— 131 —
N Item Code No. Parts Name
Price
Code
Rank
Q'ty
Specification
Standard
Model
Other
Dallas
key
Model
Standard
Model
USA
N 32 1016 5841
CABLE SUB ASSY/MIC
RJE501166*002V01 1 1 1 C
N 33 1016 5842
CHASSIS/F E820
RJE501110-001V01 1 1 1 C
N 34 1017 0488
JOINER/FFC A-E820
RJE501228-001V01 1 1 1 C
35 1008 5156
CABLE SUB ASSY/DRAWER
E440737*1 1 1 1 AK C
36 6247 2318
CABLE SUB ASSY/FG
E310997-26 1 1 1 AE C
FERRITE CORE
TR-20-10-10 1 X
4. REAR CASE BLOCK
N 37 1016 6864
CABLE SUB ASSY/DAS
RJE501164*002V01 1 1 1 C
N 38 1009 1592
SPEAKER
S065J27A 1 1 1 C
SCREW/WASHER PT
S-WBPT-3X6ZC 3 3 3 X
N 39 1017 0482
CASE SUB ASSY/REAR
RJE501227*001 1 1 1 C
39-1 1030 1145 COVER/CARD RJE501084-001V02 1 1 1 C
WASHER/PLAIN
W-6X11.5X0.8ZC 3 3 3 X
5. POWER SUPPLY PCB BLOCK
N 40 1016 5830 PCB ASSY/E820-S1 RJE501153*001V01 1 1 1 A
N IC1 1016 6848 IC LM2678SX-ADJ 1 1 1 C
R4,5
RESISTOR/CHIP
CR1/16-202JV 2 2 2 X
R6,7
RESISTOR/CHIP
CR1/16-472JV 2 2 2 X
C5
CAPACITOR/CHIP CERA
GRM188R11H333KA61D 1 1 1 X
C8,9
CAPACITOR/CHIP CERA
GRM31MR71H474KA01L 2 2 2 X
C1
CAPACITOR/CHIP AL
RV-35V101MG10U-R 1 1 1 X
D4,5 DIODE/CHIP 1SR154-400TE25 2 2 2 X
D1,2 DIODE/CHIP DE10S3L-7061 2 2 2 X
Q2,3 TRANSISTOR/CHIP 2SD1626-TD-E 2 2 2 X
L1 INDUCTOR/CHIP POWER CDRH127/LDNP-180MC 1 1 1 X
N CN9 1018 3841 CONNECTOR IMSA-9610S-25F-Y914 1 1 1 C
N CN6,7 1016 6854 CONNECTOR S3B-PH-SM4-TB(LF) 2 2 2 C
R1
RESISTOR/CHIP
CR1/16-1001FV 1 1 1 X
R2
RESISTOR/CHIP
CR1/16-3481FV 1 1 1 X
R11
RESISTOR/CHIP
CR1/16-100JV 1 1 1 X
C10
CAPACITOR/CHIP CERA
GRM1882C1H102JA01D 1 1 1 X
C4 OS-CON/CHIP 35SVPD22M 1 1 1 X
L2 BEADS/CHIP FBMH4532HM132-T 1 1 1 X
R8 RESISTOR/METAL OXIDE ERX1SJ1R5P 1 1 1 X
FU1 3000 7777 FUSE 230.600 1 1 1 AE A
N CN8 1016 6844 CONNECTOR B4P-VH(LF) 1 1 1 C
N CN2 1016 6845 CONNECTOR B2B-XH-A(LF) 1 1 1 C
N CN1 1016 6846 CONNECTOR TCS7960-53-2010 1 1 1 C
CN3-5 3000 7917 CONNECTOR ID9P33E4GX28 3 3 3 AK C
C6,7 CAPACITOR/ALE 10SEP270M 2 2 2 X
CAPACITOR/ALE RJF-35V102MI6# 2 2 2 X
6. CONNECTOR PCB BLOCK
N 41 1016 5831 PCB ASSY/E820-CNB RJE501156*001V01 1 1 1 A
N 1016 6857 CONNECTOR BM30B-SRDS-G-TFLF 1 1 1 C
N 1018 1762 CONNECTOR B2B-ZR-SM4-TF(LF) 1 1 1 C
N 1016 6856 CONNECTOR HSJ1061-01-450 2 2 2 C
3000 7917 CONNECTOR ID9P33E4GX28 3 3 3 AK C
7. LED PCB BLOCK
N 42 1016 5832 PCB ASSY/E820-LED RJE501160*001V01 1 1 1 A
R1
RESISTOR/CHIP
CR1/16-470JV 1 1 1 X
R2
RESISTOR/CHIP
CR1/16-121JV 1 1 1 X
C1
CAPACITOR/CHIP CERA
GRM188B11E104KA01D 1 1 1 X
D2,3 DIODE/CHIP 1SS400TE61 2 2 2 X
N CN2 1018 1761 CONNECTOR B3B-PH-SM4-TB(LF) 1 1 1 C
N CN1 1018 1732 CONNECTOR B2B-ZR-SM4-TF(LF) 1 1 1 C
N CN3 1018 1762 CONNECTOR B3B-ZR-SM4-TF(LF) 1 1 1 C
SW1 3412 1029 SWITCH SKHHAL 1 1 1 AA C
D1 2408 8399 LED GL3EG8 1 1 1 AA C

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
