Casio QT-6000 Service Manual

— 40 —
[ 15 ] External printer print test
[Function]
This test will check the print test for the RS232C I/F printer.
Connect the printer to the COM which is to be tested.
[Operation]
Operation : x1 x2 x3 n 0 3 d ST
X1:Print test pattern (0 = A pattern, 1 = B pattern)
X2:Port selection (1 = COM1, 2 = COM2, 3 = COM3, 4 = COM4, 5 = COM5, 6 = COM6)
X3:Baud rate selection (1 = 4800 bps, 2 = 9600 bps, 3 = 19.2 kbps)
n: 0 = One time check (can be omitted)
not 0 = Continuous check (To stop the test, press "ESC" key)
d: Printer type selection (1 = RJ, 2 = SLIP)
Note that some printers cannot use certain baud rates. Refer to the list below.
When changing the baud rate, make sure to change the setting for the printer also.
A pattern
B pattern
19.2 Kbps 9600 bps 4800 bps
SLIP PRINTER (SP1300) ✕ ΟΟ
RJ PRINTER (UP250/350/360) ΟΟΟ
BBBBBBBBBBBBBBBBBBBBB *8,888,88BBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBBB
[LCD]
PRT xxxn03d
END xxxn03d
Error display
When the printer is not connected
NON PRINTER ERR
[PRINT]
Printing pattern is the following 2 types.
The number of lines : 40 lines for RJ and 35 lines for SLIP.

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
