1. DISPLAY PCB BLOCK
N 1 1016 6273 PCB ASSY/EDP-1 RJE501147*001V01 1 A
N IC6 LSI D784216AGC8EUDB01 1 A
N IC9 1016 6277 LSI LE28F4001CTS-12L01 1 A
IC8 1016 6792 IC HIN211CAZ-T 1 A
IC3 1009 7860 IC/MOS XC6201P332MR 1 AB A
IC7 1015 6876 IC LM2611BMF 1 A
IC1 1012 0131 IC/CMOS SN74LVC08APWR 1 AC A
N IC4 1013 2445 IC/CMOS SN74LVC1G00DCKR 1 A
N IC5 1010 5293 IC/CMOS SN74LVC1G04DCKR 1 A
N IC2 1016 6278 IC/RESET S-80843CNNB-B84-T2 1 A
Q3-5 1012 0138 TRASISTOR/CHIP 2SA2018-TL 3 AC B
Q1,2,6,7 2590 2697 TRANSISTOR/CHIP DIGITAL DTC114EETL 4 AA B
X1 1014 6565 CERALOCK/CHIP CSTCE12M5G52-R0 1 AK B
L1,2 1015 6878 INDUCTOR/POWER LQH32CN220K23L 2 B
D11 DIODE/CHIP RB521S-30TE61 1 X
D10 DIODE/CHIP RB751V-40TE17 1 X
R18,19,22,72,73,76
RESISTOR/CHIP
MCR03EZPJ101 6 X
R16,23,24
RESISTOR/CHIP
MCR03EZPJ102 3 X
R6-14,25-35,37-48,
RESISTOR/CHIP
MCR03EZPJ103 47 X
R58-70,74,75
R55,56
RESISTOR/CHIP
MCR03EZPJ274 2 X
R15,17,21
RESISTOR/CHIP
MCR03EZPJ472 3 X
R1-4
RESISTOR/CHIP
MCR03EZPJ560 4 X
R5
RESISTOR/CHIP
MCR03EZPJ563 1 X
R54,57
RESISTOR/CHIP
MCR03EZPJ684 2 X
R20,71
RESISTOR/CHIP
MCR03EZPJ750 2 X
R51
RESISTOR/CHIP
MCR03EZPF2403 1 X
R50
RESISTOR/CHIP
MCR03EZPF5602 1 X
R53
RESISTOR/CHIP
MCR03EZPF8453 1 X
R49
RESISTOR/CHIP
MCR03EZPF9101 1 X
RM3,5,7,9,12-14 RESISTOR/CHIP ARRAY MNR14E0ABJ103 7 X
RM1,2,4,6,8,10,11 RESISTOR/CHIP ARRAY MNR14E0ABJ470 7 X
N TH1 1013 2898 THERMISTER NCP18WB333J03RB 1 C
C2-6
CAPACITOR/CHIP CERA
GRM1882C1H101JA01D 5 X
C1,7,8,11,12,14,15,
CAPACITOR/CHIP CERA
GRM188B11E104KA01D 13 X
C25,26,28-31
C9,10,17,18,20-22
CAPACITOR/CHIP CERA
GRM21BB11C105KA01L 7 X
C19
CAPACITOR/CHIP CERA
GRM21BB11H224KA01L 1 X
C16,23
CAPACITOR/CHIP CERA
GRM31CR61C475KA45L 2 X
C13 CAPACITOR/CHIP AL RV2-16V101MSU-R 1 X
C24,32 CAPACITOR/CHIP AL RV-10V221MG68-R 2 X
CN1 1012 0096 CONNECTOR IMSA-9632S-16Y900 1 AK C
N CN2 CONNECTOR B8B-PH-SM4-TB(LF) 1 C
N SW1,2 SWITCH/DIP A6S-4104 2 C
C27
CAPACITOR/CHIP CERA
GRM21BB1H104KA01L 1 X
D3,7 1012 0089 LED NSPG320BS(G-ST) 2 BI C
D1,4,6,9 1012 0090 LED TLOE53T 4 AD C
D2,5,8 1013 3590 LED NSPW312BSB1B2RS 3 BI C
