Casio QT-6000 - Display Block; Stand Block

— 135 —
2. DISPLAY BLOCK
N 2 1016 6707 CASE/FRONT EDP RJE501139-001V01 1 C
1012 6583 CUSION/LCD V E466 RJE500659-001V01 2 AB C
1012 6584 CUSION/LCD H E466 RJE500659-002V01 2 AB C
3 1012 0084 LCD UNIT MDG12DC38-FC 1 CQ A
N 4 1016 8763 CHASSIS/DP EDP RJE501122-001V01 1 C
N 5 1016 8764 CABLE SUB ASSY/CNB1 RJE501195*001V01 1 C
N 6 HINGE ASSY RJE501237*001V01 1 C
N 7 1016 6708 CASE/REAR EDP RJE501140-001V01 1 C
N 8 1016 8767 BOARD/DP EDP RJE501190-001V01 1 C
9 1016 8768 RUBBER/PACKING EDP RJE501191-001V01 1 C
SCREW S-PASLMA-3X5ZC 4 X
SCREW S-BDB0-3X8NI 8 X
SCREW S-BDMA-2.6X5NI 4 X
CABLE SUB ASSY/FG E440751*1 1 C
SCREW S-PASEMA-4X5ZC 2 X
N 10 1016 8762 COVER/POW-SW RJE500340-002V01 1 C
3. STAND BLOCK
N 11 1016 6709 STAND/EDP RJE501141-001V01 1 C
N 12 1016 6710 POLE/EDP RJE501142-001V01 1 C
N 13 1016 6712 SHAFT/ROTARY RJE501144-001V01 1 C
N 14 1016 6711 CAP/HINGE EDP RJE501143-001V01 1 C
N 15 1016 8769 CHASSIS/EDP RJE501123-001V01 1 C
N 16 1016 8770 CABLE SUB ASSY/CNB2 RJE501196*001V01 1 C
17 6246 6529 RUBBER/PAT ED14 E412136-1 4 AD C
SCREW S-BDB0-3X8NI 8 X
CUSHION/A EDP RJE501226-001V01 1 X
N 18 PCB ASSY/EDP-CNB1 RJE501246*001V01 1 C
D2 DIODE/CHIP 1SR154-400TE25 1 X
D1 DIODE/CHIP RSX501L-20TE25 1 X
CN1 CONNECTOR ID9P33E4GX28 1 X
CN2 CONNECTOR B8B-PH-K-S(LF) 1 X
J1 JACK/POWER HEC3600-010110 1 X
SCREW S-PASEMA-4X5ZC 1 X
SCREW S-PADLMA-3X25ZCI 4 X
N 19 1017 8517 CHASSIS/COMB A-EDP RJE501124-001V01 1 C
N 20 1017 8520 CHASSIS/COMB B-EDP RJE501193-001V01 1 C
Specification Q'ty
Price
Code
RankN Item Code No. Parts Name
