Casio QT-6000 Service Manual

— 128 —
N Item Code No. Parts Name
Price
Code
Rank
Q'ty
Specification
Standard
Model
Other
Dallas
key
Model
Standard
Model
USA
R31,178,198,252,276,
RESISTOR/CHIP
CR1/16-104JV 9 9 9 X
R278,279,319,320
R33,181,182,333
RESISTOR/CHIP
CR1/16-105JV 4 4 4 X
R277
RESISTOR/CHIP
CR1/16-113JV 1 1 1 X
R95,101,106,112,274
RESISTOR/CHIP
CR1/16-123JV 5 5 5 X
R69,297
RESISTOR/CHIP
CR1/16-201JV 2 2 2 X
R8,63,90,195
RESISTOR/CHIP
CR1/16-203JV 4 4 4 X
R180
RESISTOR/CHIP
CR1/16-243JV 1 1 1 X
R56-61,67
RESISTOR/CHIP
CR1/16-331JV 7 7 7 X
R213,215,217,220,222,
RESISTOR/CHIP
CR1/16-470JV 9 9 9 X
R223,235,236,246,334
R339
R38,91,114,123,247,
RESISTOR/CHIP
CR1/16-472JV 13 13 13 X
R249,264,280-282,
R287-289
R9,10
RESISTOR/CHIP
CR1/16-510JV 2 2 2 X
R197
RESISTOR/CHIP
CR1/16-513JV 1 1 1 X
R2,3,19-22,36,50-53,
RESISTOR/CHIP
CR1/16-563JV 37 37 37 X
R72,73,75,76,84,89,
R94,98,102,104,107,
R117,122,131,132,134,
R175,201,255,256,
R265-268,272,273
R214,216,218,219,235,
RESISTOR/CHIP
CR1/16-750JV 8 8 8 X
R236,337,338
R119
RESISTOR/CHIP
CR1/16-822JV 1 1 1 X
R125
RESISTOR/CHIP
CR1/2-5R6JV 1 1 1 X
R66,68,321,322
RESISTOR/CHIP
CR1/16-24R9FV 4 4 4 X
R283,284
RESISTOR/CHIP
CR1/16-49R9FV 2 2 2 X
R124
RESISTOR/CHIP
CR1/16-6203FV 1 1 1 X
RM6,7,9,12,37,38,41, RESISTOR/CHIP ARRAY CRA168-000V 19 19 19 X
RM46-48,51,66,67,75,
RM78,79,82,85,88
RM1,3-5,8,10,11,15,16, RESISTOR/CHIP ARRAY CRA168-103JV 26 26 26 X
RM23,28,50,52-59,61,
RM80,83,86,90,92
RM13,14,17-22,24-27, RESISTOR/CHIP ARRAY CRA168-330JV 40 40 40 X
RM29-36,39,40,42-45,
RM49,60,62-65,71-74,
RM81,84,87,89
RM68-70,76,91,93 RESISTOR/CHIP ARRAY CRA168-510JV 6 6 6 X
RM2,94-106 RESISTOR/CHIP ARRAY CRA168-563JV 14 14 14 X
C3,13,29,39,50
CAPACITOR/CHIP CERA
GRM21BB11H104KA01L 5 5 5 X
C111
CAPACITOR/CHIP CERA
GRM188B11H472KA01D 1 1 1 X
C199
CAPACITOR/CHIP CERA
GRM188B11H103KA01D 1 1 1 X
C179
CAPACITOR/CHIP CERA
GRM188B11E473KA01D 1 1 1 X
C4,6-12,15-18,23-25,
CAPACITOR/CHIP CERA
GRM188B11E104KA01D 141 141 141 X
C30-35,37,38,42-46,49,
C51,53,54,57,59,60,68,
C69,72-74,80,107,108,
C114,116-142,146-157,
C161-163,166,168-170,
C172,173,176,180-183,
C185-198,200-208,
C211-216,218-227,
C230-234
C64,67,143,184,228,
CAPACITOR/CHIP CERA
GRM188B11A105KA61D 6 6 6 X
C229

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
