Casio QT-6000 Service Manual

— 147 —
DL-2525(M type)
N Item Code No. Parts Name Specification Qt'y Price Rank
code
1 CASE/MAIN RJE500529-001 1 NOT SUPPLY X
N 1012 0508 PLATE/BOTTOM RJE500534-001 1 X
N 2 1012 0509 CHASSIS/LEFT RJE500532-001 1 X
N 3 1012 0510 CHASSIS/RIGHT RJE500533-001 1 X
N 4 1012 0511 COVER/TOP E240850-4 1 C
N 5 1012 0523 CHASSIS/BOTTOM RJE500531-001 1 X
N 6 1012 0528 LOCK SUB ASSY RJE500538*001 1 C
7 6246 5010 SPRING/PRESS E412069-1 1 AA X
N 8 1012 0529 PLATE/SPRING ED20 RJE500536-001 1 X
1008 0393 SPRING/LOCK RJE500007-001 1 AA C
SCREW 4X8 ZMC-3 3 X
N 9 1008 7972 SOLENOID SUB ASSY RJE500128*003 1 B
N 1008 0964 SWITCH/MICRO VX-013-1A3 1 B
SCREW 3X14 ZMC-3 2 X
TIE/INSULICK T-18S 1 X
10 5500 0619 ROLLER/DELRIN DR-19B1 2 AG B
NUT/HEX 6 ZMC-3 2 X
WASHER 6X13X1.0 ZMC-3 2 X
11 1008 0450 RUBBER/DUMPER RJE500005-001 4 AB X
SCREW 4X5 ZMC-3 3 X
12 1007 8903 DRAWER SUB ASSY E341274*1 1 BJ X
13 5500 0619 ROLLER/DELRIN DR-19B1 2 AG B
14 5200 0106 RIVET 5X30 1 AA X
15 6246 5030 SPRING/EARTH E412092-1 1 AA X
16 1007 9060 LOCK/CYLINDER CL-16 1 BA C
N 17 1012 1046 PANEL/FRONT RJE500530-001 1 X
SCREW 3X10 NI 2 X
5440 0399 WASHER 6X13X1.0 ZMC-3 2 AA X
18 1007 8757 CASE/BILL E140505-1 1 AT C
N 19 1010 6267 CASE/COIN RJE500284-1 1 AH C
N 20 1011 0335 PLATE/COIN CASE PARTITION RJE500285-1 5 AA B
21 1010 6268 PLATE/BILL CASE PARTITION RJE500219-001 3 AA B
22 1007 9062 BILL HOLDER SUB ASSY E341290*1 4 AE B
23 1007 9063 SPRING/BILL HOLDER E441357-1 4 AA C
24 1007 9064 BRACKET/BILL HOLDER E240845-1 1 AD X
SCREW 3X8 ZMC-3 3 X
SCREW 3X5 NI 4 X
SCREW 3X6 ZMC-3 15 X
N 25 1008 6054 FG CABLE SUB ASSY RJE500104*001 1 X
SCREW 3X6 ZMC-3 3 X
WASHER 4 1 X
LABEL/DL-2525 E341256-34 1 X
N 26 1012 5287 CASE/RUBBER RJE500667-001 4 C
27 6246 6529 RUBBER/PAD E412136-1 4 AD C
SCREW 4X8 ZMC-3 4 X
N 1013 1033 PLATE/FIX RJE500775-001 2 X

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
