Casio QT-6000 Service Manual

— 149 —
DL-3616 (L type)
N Item Code No. Parts name Specification Q'ty Price Code RANK
2 1907 7272 LOCK ASSY ZD00290-0 1 BZ B
3 1906 0672 NUT M4XP0.7 2 AA X
N 4 9487 0383 LABEL DL-3616 1 AL X
N 5 1907 9613 WIRE/FG ZD31670 1 AI X
6 1907 0223 CONNECTOR 1625-03PI 1 AL X
7 1902 7112 GROMET B-1 1 AB X
11 1902 7076 SPRING ZD01370B 1 AC C
12 1902 6829 RUBBER/DAMPER K2320 1 AC X
13 1907 0234 SCREW/TAPPING M4X16 1 AA X
15 1902 6842 ROLLER/DERLIN DR-19B 4 AH B
16 1906 0679 DRAWER SUB ASSY ZD58120 1 CF X
17 1902 6992 LEVER/OPEN ZD00250 1 AN X
18 1907 7930 SPRING/OPEN LEVER ZD00254 1 AB C
19 1906 0680 SCREW/TAPPING M3X4 2 AA X
20 1906 4150 RIVET 쏗5X30 1 AA X
21 5580 1452 RING/CS CSTW-5 1 AA X
22 1906 0683 PANEL/FRONT ZD56721 1 BH X
23 1906 0684 SCREW/TAPPING M3.5X8 2 AA X
24 1902 7027 KEY/CYLINDER ZD00226 1 BB C
25 1907 7928 CLIP ZD00226-2 1 AJ X
26 1906 0685 CASE/BILL ZD04851 1 BO C
27 1907 7926 CASE/COIN ZD04843PS 1 BN C
28 1907 7925 PLATE/BILL PARTITION ZD04842 4 AH C
29 1907 7924 PLATE/COIN PARTITION ZD04844 5 AD C
30 1907 7923 HOLDER/PARTITION PLATE ZD04845 5 AC
X
31 1902 6991 PLATE/BILL HOLDER FIXING ZD00245 1 AK X
32 9487 0385 STOPPER/BILL HOLDER ZV27041-1 5 AE X
33 6221 4902 HOLDER/BILL ZD18931 5 AC B
34 6221 4904 SPRING/BILL HOLDER ZD18932 5 AB B
35 1902 6987 SCREW/TAPPING M3X8 5 AA X
36 1902 7093 SCREW/TAPPING M3X6 6 AA X
37 1907 7922 PLATE/BOTTOM ZD18031 1 CB X
38 1906 0689 RUBBER/DAMPER ZD02032 2 AE X
39 1902 7046 FOOT/RUBBER K3215 4 AJ X
40 1907 0234 SCREW/TAPPING M4X16 4 AA X
41 1906 0691 SCREW/TAPPING M3X5 5 AA X
42 1907 7920 CUSHION ZD05422 1 AE X
43 1902 6214 KEY ZD00226-1 1 AU C
44 1907 7943 LEVER/SWITCH ZD00283 1 AL C
45 1907 7942 SWITCH/MICRO SS-01GL-ET 1 BF B
49 1907 9615 EARTH/SPRING ZD02162C 1 AE C

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
