Casio QT-6000 Service Manual

— 73 —
PIN NAME I/O DESCRIPTION
HVDD
MVDD
FPVDD
VPVDD
CVDD
AVDD
RVDD
CVSS
AVSS1
AVSS2
RVSS
VDD
VSS
Host Interface VDD on I/O Ring, 3.3V
Display Memory Interface VDD on I/O Ring, 3.3V
Flat Panel Interface VDD on I/O Ring, 3.3V
VPVDD VPort Interface VDD on I/O Ring 3.3V
Clock (PLL) Analog Power, 3.3V
DAC Analog Power, 3.3V
RAM Filtered Palette Power, 3.3V
PLL Analog Ground
DAC Analog Ground
DAC Analog Ground
RAM Filtered Palette Ground
Digital 3.3V Core Power Supply
Digital 3.3V Internal Memory Power Supply
Digital Ground
VCC and GROUND Pins

Casio QT-6000 Specifications

General

Types of payment	Cash
Second display	Yes
Second display type	LED
Power source	AC
AC input voltage	120-240 V
Power consumption	1100 mA
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	311 mm
Width	343 mm
Height	288 mm
Weight	5300 g
