CESSNA SECTION 5
MODEL
2088 (675 SHP) PERFORMANCE
TABLE OF CONTENTS (Continued) Page
Figure 5-26 Climb Gradient
. Takeoff Flap Setting ............. 5.66
Figure 5-27 Maximum Rate Of Climb
. Flaps Up .............. 5.67
Figure 5-28 Takeoff Climb Gradient
. Flaps Up ................ 5.68
Figure 5-29 Cruise Climb
. Flaps Up . 115 KIAS ............... 5.69
Figure 5-30 Rate Of Climb
. Balked Landing .................. 5.70
Figure 5-31 Time, Fuel, And Distance To Climb
.
Maximum Rate Of Climb ..................... 5.71
Time, Fuel, And Distance To Climb
.
Cruise Climb . 115 KlAS ..................... 5.72
Figure 5-32 Cruise Performance
. Notes ..................... 5.73
Cruise Performance
. 2000 Feet ................. 5.74
Cruise Performance
. 4000 Feet ................. 5.75
Cruise Performance
. 6000 Feet ................. 5.76
Cruise Performance
. 8000 Feet ................. 5.77
Cruise Performance
. 10, 000 Feet ................ 5.78
Cruise Performance
. 12, 000 Feet ................ 5.79
Cruise Performance
. 14, 000 Feet ................ 5.80
Cruise Performance
. 16.000 Feet ................ 5.81
Cruise Performance
. 18, 000 Feet ................ 5.82
................ Cruise Performance . 20, 000 Feet 5.83
................ Cruise Performance . 22, 000 Feet 5.84
................ Cruise Performance . 24, 000 Feet 5.85
Figure 5-32A Cruise Maximum Torque (Sheet 1 of 5)
........... 5.86
Figure 5-32A Cruise Maximum Torque (Sheet 2 of 5)
........... 5.87
Figure 5-32A Cruise Maximum Torque (Sheet 3 of 5)
........... 5.88
........... Figure 5-32A Cruise Maximum Torque (Sheet 4 of 5)
5.89
........... Figure 5-32A Cruise Maximum Torque (Sheet 5 of 5)
5.90
Figure 5-33 Fuel And Time Required
. Maximum Cruise Power
(40-200 NM)
.............................. 5.91
Fuel And Time Required
. Maximum Cruise Power
............................
(200-1 000 NM) 5.92
Figure 5-34 Fuel And Time Required
. Maximum Range Power
(40-200 NM)
.............................. 5.93
Fuel And Time Required
. Maximum Range Power
............................
(200-1000 NM) 5.94
................................
Figure 5-35 Range Profile 5.95
.............................
Figure 5-36 Endurance Profile 5.96
.............
Figure 5-37 Time, Fuel, And Distance To Descend
5.97
............ .
Figure 5-38 Landing Distance 8500 Lbs, 8000 Lbs 5.98
...... .
Landing Distance 7500 Lbs, 7000 Lbs .5.99/ 5.100
