SECTION 7 CESSNA
AIRPLANE AND SYSTEMS DESCRIPTION MODEL
2088 (675 SHP)
TABLE OF CONTENTS (Continued) Page
..................................
Engine Instruments 7-52
..................................
Torque Indicator 7-52
............................
Propeller RPM Indicator 7-53
.....................................
ITT Indicator 7-53
.................................
Ng RPM Indicator 7-53
Fuel Flow Indicator
................................ 7-53
................................
Oil Pressure Gage 7-54
Oil Temperature Gage
............................. 7-54
.....................
New Engine Break-In and Operation
7-54
Engine Lubrication System
............................ 7-55
.....................................
Ignition System 7-57
.................................
Air Induction System 7-58
.............................
Inertial Separator System 7-58
.....................................
Exhaust System 7-60
..................................
Engine Fuel System 7-60
.....................................
Cooling System 7-61
.....................................
Starting System 7-62
..................................
Engine Accessories 7-62
OilPump ........................................ 7-63
FuelPump ...................................... 7-63
..........................
Ng Tachometer-Generator 7-63
.....................
Propeller Tachometer-Generator 7-64
.....................................
Torquemeter 7-64
.................................
StarterIGenerator 7-64
lnterturbine Temperature Sensing System
.............. 7-65
................................
Propeller Governor 7-65
Propeller Overspeed Governor
....................... 7-66
EngineMount .................................... 7-66
Engine Fire Detection System
....................... 7-66
Engine Gear Reduction System
...................... 7-67
Chip Detectors (Optional)
........................... 7-67
.............................
Oil Breather Drain Can 7-68
Propeller
............................................. 7-68
Overspeed Governor Test Switch
....................... 7-69
Fuelsystem .......................................... 7-70
Firewall Fuel Shutoff Valve ............................ 7-74
..................................
Fuel Tank Selectors 7-74
Fuel Selectors Off Warning System
...................... 7-75
...........................
Auxiliary Boost Pump Switch 7-76
1 7-2 U.S. Revision 23
