ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 3: Preparing an ASX-500/510 Autosampler
24
Install the 1.0mm ID Sample Probe on the
Autosampler
A 1.0mm ID sample probe (Figure 3-5) is provided for use with the CETAC
autosampler for proper operation with the ASXpress
PLUS system. Follow the
autosampler Operator Manual Instructions to replace the probe with the
1.0mm sample probe, which is attached to the ASX
PRESS PLUS 6-port valve at
Port #2.
NOTE
The 1.0mm I.D. sample probe must be installed on the autosampler or the
ASXPRESS PLUS Rapid Sample Introduction System will not perform properly. It is
identified by double blue bands (Figure 3-5) installed on the probe tubing.
Figure 3-5 Double Blue Bands Identify the 1.0mm I.D. Sample Probe
(carbon fiber probe is shown)
