ASXPRESS PLUS Rapid Sample Introduction System Operator’s Manual
Chapter 5: Preparing an ASX-1400/1600 Autosampler
62
NOTE
The 1.0mm I.D. sample probe must be installed on the autosampler or the
ASXPRESS PLUS Rapid Sample Introduction System will not perform properly. It is
identified by double blue bands (Figure 5-12) installed on the probe tubing.
Figure 5-12 Double Blue Bands Identify the 1.0mm I.D. Sample Probe
(carbon fiber probe shown is standard equipment)
Figure 5-13 Sample Probe/Stirrer Holder Block for 1.0mm I.D. Sample Probe
Removing the Sample Probe
1 Remove the thumbscrew and pull the sample probe straight out and put it
aside.
