CG Emotron VFX Series User Manual

176 CG Drives & Automation, 01-5326-01r5
AnOut1 Max [5332]
This parameter is automatically displayed if User mA or
User V is selected in menu “AnOut1 Setup [532]”. The
menu will automatically adapt to current or voltage setting a
ccording to the selected setup. Only visible if [532] = User
mA/V.
Communication information
AnOut1 Bipol [5333]
Automatically displayed if User Bipol mA or User Bipol V is
selected in menu AnOut1 Setup. The menu will
automatically show mA or V range according to the selected
function. The range is set by changing the positive
maximum value; the negative value is automatically adapted
accordingly. Only visible if [512] = User Bipol mA/V.
Communication information
AnOut1 Function Min [5334]
With AnOut1 Function Min the physical minimum value is
scaled to selected presentation. The default scaling is
dependent of the selected function of “AnOut1 [531]”.
Table 38 shows corresponding values for the min and max
selections depending on the function of the analogue output
[531].
*) Fmin is dependent on the set value in menu
“Minimum Speed [341]”.
Communication information
5332 AnOut 1 Max
Default: 20.00 mA
Range: 0.00–20.00 mA, 0–10.00 V
Modbus Instance no/DeviceNet no: 43254
Profibus slot/index 169/158
EtherCAT and CANopen index (hex) 4cb6
Profinet IO index 19638
Fieldbus format
Long, 1=0.01 V,
0.01 mA
Modbus format EInt
5333 AnOut1Bipol
Default: -10.00–10.00 V
Range: -10.00–10.00 V, -20.0–20.0 mA
Modbus Instance no/DeviceNet no: 43255
Profibus slot/index 169/159
EtherCAT and CANopen index (hex) 4cb7
Profinet IO index 19639
Fieldbus format
Long, 1=0.01 V,
0.01 mA
Modbus format EInt
5334 AnOut1FCMin
Default: Min
Min 0 Min value
Max 1 Max value
User-defined 2 Define user value in menu [5335]
Ta b l e 3 8
AnOut
Function
Min Value Max Value
Process Value Process Min [324] Process Max [325]
Speed Min Speed [341] Max Speed [343]
Torque 0% Max Torque [351]
Process Ref Process Min [324] Process Max [325]
Shaft Power 0% Motor Power [223]
Frequency Fmin * Motor Frequency [222]
Current 0 A Motor Current [224]
El Power 0 W Motor Power [223]
Output
Voltage
0 V Motor Voltage [221]
DC voltage 0 V 1000 V
AnIn1
AnIn1 Function
Min
AnIn1 Function Max
AnIn2
AnIn2 Function
Min
AnIn2 Function Max
AnIn3
AnIn3 Function
Min
AnIn3 Function Max
AnIn4
AnIn4 Function
Min
AnIn4 Function Max
Modbus Instance no/DeviceNet no: 43256
Profibus slot/index 169/160
EtherCAT and CANopen index (hex) 4cb8
Profinet IO index 19640
Fieldbus format UInt
Modbus format UInt
