Example
Set the AnOut function for Motorfrequency to 0Hz, set
AnOut functionMin [5334] to “User-defined” and AnOut1
VaMin[5335] = 0.0. This results in an anlogue output signal
from 0/4 mA to 20mA: 0Hz to Fmot.
This principle is valid for all Min to Max settings.
AnOut1 Function Value Min [5335]
With AnOut1 Function VaMin you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
Communication information
AnOut1 Function Max [5336]
With AnOut1 Function Max the physical minimum value is
scaled to selected presentation. The default scaling is
dependent on the selected function of AnOut1 [531]. See
Table 38.
Communication information
AnOut1 Function Value Max [5337]
With AnOut1 Function VaMax you define a user-defined
value for the signal. Only visible when user-defined is
selected in menu [5334].
Communication information
AnOut2 Function [534]
Sets the function for the Analogue Output 2.
Communication information
AnOut2 Setup [535]
Preset scaling and offset of the output configuration for
analogue output 2.
Communication information
5335 AnOut1VaMin
Default: 0.000
Range: -10000.000–10000.000
Modbus Instance no/DeviceNet no: 43545
Profibus slot/index 170/194
EtherCAT and CANopen index (hex) 4dd9
Profinet IO index 19929
Fieldbus format
Long,
1=1 rpm, 1 %, 1W,
0.1 Hz, 0.1 V, 0.1 A or
0.001 via process value
[322]
Modbus format EInt
5336 AnOut1FCMax
Default: Max
Min 0 Min value
Max 1 Max value
User defined 2 Define user value in menu [5337]
Modbus Instance no/DeviceNet no: 43257
Profibus slot/index 169/161
EtherCAT and CANopen index (hex) 4cb9
Profinet IO index 19641
Fieldbus format UInt
Modbus format UInt
NOTE: It is possible to set AnOut1 up as an inverted
output signal by setting AnOut1 Min > AnOut1 Max.
See Fig. 129, page 168.
5337 AnOut1VaMax
Default: 0.000
Range: -10000.000–10000.000
Modbus Instance no/DeviceNet no: 43555
Profibus slot/index 170/204
EtherCAT and CANopen index (hex) 4de3
Profinet IO index 19939
Fieldbus format
Long,
1=1 rpm, 1 %, 1W,
0.1 Hz, 0.1 V, 0.1 A or
0.001 via process value
[322]
Modbus format EInt
534 AnOut2 Fc
Default: Torque
Selection: Same as in menu
[531]
Modbus Instance no/DeviceNet no: 43261
Profibus slot/index 169/165
EtherCAT and CANopen index (hex) 4cbd
Profinet IO index 19645
Fieldbus format UInt
Modbus format UInt
535 AnOut2 Setup
Default: 4-20mA
Selection: Same as in menu
[532]
Modbus Instance no/DeviceNet no: 43262
Profibus slot/index 169/166
EtherCAT and CANopen index (hex) 4cbe
Profinet IO index 19646
Fieldbus format UInt
Modbus format UInt
