CG Emotron VFX Series User Manual

CG Drives & Automation, 01-5326-01r5 Mounting 17
Fig. 12 Emotron VFX Model 69-002 to 025 (Frame size
C69).
Table 8 Dimensions connected to Fig. 12.
Fig. 13 Cable interface for mains, motor and communication,
Emotron VFX Model 69-002 to 025 (Frame size
C69).
C
F
G
A
B
E
D
17 kg
(37.4 lb)
(0.27 in)
ø13 mm(x2)
(0.51 in)
ø7mm (x4)
Glands
Gland
M25
Glands
M20
M32
Frame
size
Emotron
VFX
model
Dimensions in mm (in)
A B C D E F
G
(depth)
C69 002-025
512
(20.2)
492
(19.4)
128.5
(5.06)
24.8
(0.98)
10
(0.39)
178
(7.01)
314 (12.36)
Excl. PPU G
291.5 (11.5)
