CG Emotron VFX Series User Manual

208 CG Drives & Automation, 01-5326-01r5
Digital Output Status [724]
Indicates the status of the digital outputs and relays. See Fig.
144.
RE indicate the status of the relays on position:
1Relay1
2Relay2
3Relay3
DO indicate the status of the digital outputs on position:
1DigOut1
2DigOut2
The status of the associated output is shown.
1High
0Low
The example in Fig. 144 indicates that DigOut1 is active
and Digital Out 2 is not active. Relay 1 is active, relay 2 and
3 are not active.
Fig. 144 Digital output status example
Communication information
Analogue Input Status [725]
Indicates the status of the analogue inputs 1 and 2.
Fig. 145 Analogue input status
Communication information
The first row indicates the analogue inputs.
1 AnIn 1
2 AnIn 2
Reading downwards from the first row to the second row the
status of the belonging input is shown in %:
-100% AnIn1 has a negative 100% input value
65% AnIn2 has a 65% input value
So the example in Fig. 145 indicates that both the Analogue
inputs are active.
Analogue Input Status [726]
Indicates the status of the analogue inputs 3 and 4.
Fig. 146 Analogue input status
Communication information
Modbus Instance no/DeviceNet no: 31018
Profibus slot/index 121/162
EtherCAT and CANopen index (hex) 23fa
Profinet IO index 1018
Fieldbus format UInt,
bit 0=DigOut1,
bit 1=DigOut2
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
Modbus format
724 DigOutStatus
Stp RE 100 DO 10
Modbus Instance no/DeviceNet no: 31019, 31020
Profibus slot/index 121/163, 121/164
EtherCAT and CANopen index (hex) 23fb, 23fc
Profinet IO index 1019, 1020
Fieldbus format Long, 1=1%
Modbus format EInt
NOTE: The shown percentages are absolute values
based on the full range/scale of the in- or output; so
related to either 0–10 V or 0–20 mA.
Modbus Instance no/DeviceNet no: 31021, 31022
Profibus slot/index 121/165, 121/166
EtherCAT and CANopen index (hex) 23fd, 23fe
Profinet IO index 1021, 1022
Fieldbus format Long, 1=1%
Modbus format EInt
725 AnIn 1 2
Stp -100% 65%
726 AnIn 3 4
Stp -100% 65%
