CG Emotron VFX Series User Manual

CG Drives & Automation,01-5326-01r5 207
Warning [722]
Display the actual or last warning condition. A warning
occurs if the AC drive is close to a trip condition but still in
operation. During a warning condition the red trip LED
will start to blink as long as the warning is active.
The active warning message is displayed in menu [722]. If
no warning is active the message “No Error” is displayed.
The following warnings are possible:
Communication information
See also the Chapter 12. page 217.
Digital Input Status [723]
Indicates the status of the digital inputs. See Fig. 143.
1DigIn 1
2DigIn 2
3DigIn 3
4DigIn 4
5DigIn 5
6DigIn 6
7DigIn 7
8DigIn 8
The positions one to eight (read from left to right) indicate
the status of the associated input:
1High
0Low
The example in Fig. 143 indicates that DigIn 1,
DigIn 3 and DigIn 6 are active at this moment.
Fig. 143 Digital input status example
Communication information
Communication
integer value
Warning message
0No Error
1 Motor I²t
2PTC
3 Motor lost
4 Locked rotor
5 Ext trip
6Mon MaxAlarm
7Mon MinAlarm
8Comm error
9 PT100
10 Crane Derivat
11 Pump
12 Ext Mot Temp
13 LC Level
14 Brake
15 Option
16 Over temp
17 Over curr F
18 Over volt D
19 Over volt G
20 Over volt
21 Over speed
22 Under voltage
23 Power fault
24 Desat
25 DClink error
26 Int error
27 Ovolt m cut
28 Over voltage
722 Warnings
Stp warn.msg
29 Not used
30 Crane Comm
31 Encoder
Modbus Instance no/DeviceNet no: 31016
Profibus slot/index 121/160
EtherCAT and CANopen index (hex) 23f8
Profinet IO index 1016
Fieldbus format UInt
Modbus format UInt
Modbus Instance no/DeviceNet no: 31017
Profibus slot/index 121/161
EtherCAT and CANopen index (hex) 23f9
Profinet IO index 1017
Fieldbus format UInt,
bit 0=DigIn1,
bit 7=DigIn8
Modbus format
Communication
integer value
Warning message
723 DigIn Status
Stp 1010 0100
