CG Emotron VFX Series User Manual

20 Mounting CG Drives & Automation, 01-5326-01r5
Fig. 22 Emotron VFX/ Model 48-142 to
48-171 (Frame size E2).
Fig. 23 Bottom view Emotron VFX/ Model 48-142 to 48-293
(Frame size E2 and F2), with cable interface for
mains, motor, DC+/DC-, brake resistor and control.
(principle drawing).
Fig. 24 Emotron VFX/ Model 48-205 to
48-293 (Frame size F2) and 48-365-20 (Frame size
FA2).
C
H
D
A
B
E
G
F
ø16 mm(x3)
(0.63 in)
ø9 mm(x6)
(0.35 in)
53 kg
(117 lb)
D
E
ø16 mm(x3)
(0.63 in)
ø9 mm(x6)
(0.35 in)
A
B
C
H
F
G
F2
68 kg
(150 lb)
FA2
84 kg
(185 lb)
Table 11 Dimensions IP20 connected to Fig. 22 and Fig. 24.
Frame
size
Emotron VFX
model
Dimension in mm (in)
A B C D E F
G
(depth)
H
E2 142 - 171
925
(36.4)
950
(37.4)
240
(9.5)
22.5
(0.88)
10
(0.39)
275
(10.8)
294 (11.6)
IP21 - 323 (12.7)
120
(4.7)
F2 205 - 293
300
(11.8)
335
(13.2)
294 (11.6)
IP21 - 323 (12.7)
150
(5.9)
FA2 365
1065
(41.9)
1090
(42.9)
306 (12)
IP21 - 323 (12.7)
