Status Parameter Setup
Mode l8500C/8500C+ Operators Manual
9-5
9.3.4 Clearing Review Item
The
CLEAR ITEM
soft key deletes the currently displayed item and removes it from memory. An item
next stored in memory is displayed in its place. Note that if the deleted item is also the current item in
Balance mode, that balance history is also deleted, and is not available when you return to the Balanc
mode.
To delete all the items of the selected data type, press
CLEA RALL
. If the data type is
<ANY>
, all
spectral and balance history items are deleted.
9.3.5 Analyzing the Selected Item
The
ANALYZE
soft key restores the selected item and makes it the current plot or history in the
Balance or Spectrum mode. Use
ANALYZE
, for instance, to restore an old balance history so that new
runs can be taken and added to it. Note that the history that was in use befor
ANALYZE
was pressed is
superseded by the restored item, and that the balance chart associated with the restored item is also
made the current chart.
9.4 Status Parameter Setup
The 8500C/C+ supports the modification of several Status screen parameters. These parameters may
be accessed by pressing
SETUP
, which in turn displays the Status Setup screen (Fig ure9-4). See th
description of th
SETUP
key in Secti on4.2.3.4 “SETUP Key” on page4-7 for more information on
Setup screens.
Figure 9-4. Status Setup Screen
Use the Arro wkeys to select the field whose contents are to be modified, and th
<CHANGE>
soft key
or the numeric keypad to effect the desired changes. Th
ENTER
soft key saves the changes, quits
status mode, and returns the 8500C/C+ to its previous mode of operation. Pressing the
START
key has
the same effect. The
RESTORE
soft key restores to all fields the values that were set by the most recent
ENTER
. Pressing
STATUS
performs an implicit
ENTER
and returns to the Status screen.
The following sections describe in greater detail the various Status Setup screen fields.
