Chapter 3
Mode l8500C/8500C+ Operators Manual
3-1
3.
Unpacking and Installation
The Model8500C/C+ Balancer/Analyzer is a self-contained kit packed in a rugged case. All the
accessories needed for operation are included in the kit. Complete unpacking instructions for the kit
are included in the Mod el8500C/C+ System Maintenance Manual. The information in this chapter is a
brief summary. Chapter 3 gives you unpacking and installation information, under the following
topics:
Section 3.1 Mode l8500C/C+ and Installation....................................................................3-1
Section 3.2 Signal Selector and Installation........................................................................3-2
3.1 Model 8 5 00C/C+ and Installation
Figur e3-1 on page3-2 shows a top and front view of the 8500C/C+ . The Model135M-12 Strobex and
28-Vdc power/signal connectors are on the right side. The liquid-crystal display (LCD) contrast
adjustment is on the left. The disk drive door is on the front of the unit.
CAUTION: The 8500C/C+ can only operate from a 28-Vdc power supply. Plugging the
8500C/C+ into a power source other t han 28Vdc may cause severe damage to the
instrument.
